Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
384 Managing Hosts
Figure 418: Main Interface Settings Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen interface.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.17.10
Managing Hosts
Hosts are used to assign zones to individual hosts or subnets (if the interface supports multiple subnets). This
allows the firewall to receive a packet and then redirect it to the same device that received it. This is functionality
is useful for VPN setups to handle the VPN traffic separately from the other traffic on the interface which carries
the VPN traffic.
Table: Example
Zone Interface IP Address or Network
Local Switch.0003 10.0.0.0/8
Guests Switch.0003 192.168.0.0/24
The following sections describe how to configure and manage hosts for a firewall:
• Section 5.17.10.1, “Viewing a List of Hosts”
• Section 5.17.10.2, “Adding a Host”
• Section 5.17.10.3, “Deleting a Host”
Section 5.17.10.1
Viewing a List of Hosts
To view a list of hosts, navigate to security » firewall » fwconfig » {firewall} » fwhost, where {firewall} is the
name of the firewall. If hosts have been configured, the Main Host Settings table appears.
