Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
382 Configuring a Broadcast Address
Figure 416: Zone Form
1. Predefined Zone List 2. Undefined Zone Check Box
3. Configure the following parameter(s) as required:
Parameter Description
predefined-zone A pre-defined zone
undefined-zone This is used in conjunction with hosts definitions.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.17.9.4
Configuring a Broadcast Address
To configure a broadcast address for an interface, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to security » firewall » fwconfig » fwconfig » {firewall} » fwinterface{interface} » broadcast-
addr, where {firewall} is the name of the firewall and {interface} is the name of the interface. The Broadcast
Address form appears.
