Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
406 Enabling/Disabling a Firewall
Section 5.17.16
Enabling/Disabling a Firewall
To enable or disable the firewall, do the following:
IMPORTANT!
Enabling or disabling the firewall will reset – but not disable – the BFA protection mechanism, if
previously enabled. Any hosts that were previously blocked will be allowed to log in again. If multiple
hosts are actively attacking at the time, this could result in reduced system performance.
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to security » firewall. The Firewall Configuration form appears.
Figure 445: Firewall Configuration Form
1. Enable Active Configuration Check Box 2. Specify Work Configuration List 3. Specify Active Configuration List
3. Under Specify active configuration, select the firewall configuration from the list to enable.
4. Select the Enabled check box to enable the firewall or clear the check box to disable the firewall.
5. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
6. Click Exit Transaction or continue making changes.
Section 5.18
Managing IS-IS
Intermediate System - Intermediate System (IS-IS) is one of a suite of routing protocols tasked with sharing
routing information between routers. The job of the router is to enable the efficient movement of data over
sometimes complex networks. Routing protocols are designed to share routing information across these networks
and use sophisticated algorithms to decide the shortest route for the information to travel from point A to point B.
One of the first link-state routing protocols was IS-IS developed in 1986 and later published in 1987 by ISO as
ISO/IEC 10589. It was later republished as an IETF standard (RFC 1142 [http://tools.ietf.org/html/rfc1142]).
IS-IS is an Interior Gateway Protocol (IGP) meant to exchange information between Autonomous Systems (AS).
It is designed to operate within an administrative domain or network using link-state information to decide optimal
data packet routing, similar to OSPF. IS-IS floods the network with link-state information and builds a database of
