RUGGEDCOM ROX II
User Guide
Chapter 3
Device Management
Viewing the Parts List 37
Figure 25: Power Status Table
This table provides the following information:
Parameter Description
PM Slot Synopsis: pm1, pm2
The name of the power module slot as labeled on the chassis.
MOV Protection Synopsis: na, working, damaged
The state of the MOV protection circuit.
PM Temperature (C) The temperature (Celsius) inside the power module.
PM Current (mA) The current (mA) sourced by the power module.
PM Voltage (mV) The voltage (mV) sourced by the power module.
Section 3.3
Viewing the Parts List
To view a list of parts installed in the device, navigate to chassis » part-list. The Module Database table
appears.
Figure 26: Module Database Table
