Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
762 Adding a Traffic Control Priority
If no priorities have been configured, add priorities as needed. For more information, refer to Section 5.37.3.2,
“Adding a Traffic Control Priority”.
Section 5.37.3.2
Adding a Traffic Control Priority
To add a new traffic control priority, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to qos » traffic-control » basic-configuration » tcpriorities, and click <Add tcpriorities>. The
Key Settings form appears.
1
2
Figure 876: Key Settings Form
1. Name Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
name A distinct name for this configuration entry.
4. Click Add to create the new traffic control priority. The Basic Traffic Control Priorities form appears.
