RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Viewing a List of Prefix Entries 481
Figure 544: Prefix List Table
If no prefix lists have been configured, add lists as needed. For more information, refer to Section 5.20.3.3,
“Adding a Prefix List”.
Section 5.20.3.2
Viewing a List of Prefix Entries
To view a list of entries for dynamic RIP prefix lists, navigate to routing » dynamic » rip » filter » {name} »
entry, where {name} is the name of the prefix list. If entries have been configured, the Prefix List Entry table
appears.
Figure 545: Prefix List Entry Table
If no entries have been configured, add entries as needed. For more information, refer to Section 5.20.3.4,
“Adding a Prefix Entry”.
Section 5.20.3.3
Adding a Prefix List
To add a prefix list for dynamic RIP routes, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » rip » filter and click <Add prefix-list>. The Key Settings form appears.
