Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
474 Adding a Redistribution Metric
Figure 535: Redistribute Route from Other Protocols Table
If no redistribution metrics have been configured, add metrics as needed. For more information, refer to
Section 5.19.11.2, “Adding a Redistribution Metric”.
Section 5.19.11.2
Adding a Redistribution Metric
To add a redistribution metric for dynamic BGP routes, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » bgp » redistribute and click <Add redistribute>. The Key Settings form
appears.
Figure 536: Key Settings Form
1. Redistribute Route From List 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
Redistribute Route From Synopsis: kernel, static, connected, ospf, rip
Redistribute route type.
4. Click Add to add the metric. The Redistribute Route From Other Protocols form appears.
