Chapter 2

Using ROX II

RUGGEDCOM ROX II

User Guide

14 Connecting Through the Network

Figure 1: MGMT Port

2. By default, the RUGGEDCOM RX1500 has a different IP address and subnet configured for two types of IP

interfaces, both of which are mapped to one or more physical ports:

Port IP Address/Mask

MGMT 192.168.1.2/24

All other Ethernet ports 192.168.0.2/24

For example, if the device is connected via the MGMT port, configure the computer's Ethernet port with

an IP address in the range of 192.168.1.3 to 192.168.1.254. Connect to the device using the IP address

192.168.1.2, the address of the MGMT interface.

3. Launch the SSH client on the computer and connect to admin@{ipaddress}, where {ipaddress} is the IP

address for the MGMT port. The login prompt appears:

Using username "admin".

admin@192.168.0.2's password:

4. Log in to ROX II. For more information about logging in to ROX II, refer to Section 2.3, “Logging In”.

Section 2.1.2

Connecting Through the Network

To connect to ROX II through the network, do the following:

1. On the computer being used to connect to the device, configure the Ethernet port to use an IP address falling

within the subnet of the device.

By default, the RUGGEDCOM RX1500 has a different IP address and subnet configured for two types of IP
