RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Managing Aggregate Addresses 469
Figure 528: Track Form
1. Event List 2. Apply When List
4. Configure the following parameter(s) as required:
Parameter Description
Event Select an event.
Apply When Synopsis: up, down
Default: up
Apply when the tracked event state goes UP or DOWN.
5. Click Add to create the tracker.
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
Section 5.19.9
Managing Aggregate Addresses
The following sections describe how to configure and manage aggregate addresses:
• Section 5.19.9.1, “Viewing a List of Aggregate Addresses”
• Section 5.19.9.2, “Adding an Aggregate Address”
• Section 5.19.9.3, “Deleting an Aggregate Address”
Section 5.19.9.1
Viewing a List of Aggregate Addresses
To view a list of aggregate addresses for dynamic BGP routes, navigate to routing » dynamic » bgp »
aggregate-address. If addresses have been configured, the Aggregate Network table appears.
