Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
318 Configuring Shared Network Options
Section 5.15.6.3
Configuring Shared Network Options
To configure options for a shared network on the DHCP server, do the following:
NOTE
Options set at the shared network level override options set at the DHCP server level.
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to services » dhcpserver » shared-network{shared network} » options, where {shared
network} is the name of the shared network. The Leased Configuration and Client Configuration forms
appear.
Figure 337: Leased Configuration Form
1. Default Box 2. Maximum Box
Figure 338: Client Configuration Form
1. Unknown Client List 2. Authorize Server Check Box 3. Option 82 Check Box
3. On the Leased Configuration form, configure the following parameters as required:
Parameter Description
default Default: 600
