Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
478 Viewing the Status of Dynamic RIP Routes
Parameter Description
The routing table update timer (in seconds).
Timeout Timer Default: 180
The routing information timeout timer (in seconds).
Garbage Collection Timer Default: 120
The garbage collection timer (in seconds).
4. In the RIP Configuration form, configure the following parameters:
Parameter Description
Enable RIP Enables the RIP dynamic routing protocol.
Default Information Originate The route element makes a static route only inside RIP. This element should be used
only by advanced users who are particularly knowledgeable about the RIP protocol. In
most cases, we recommend creating a static route and redistributing it in RIP using the
redistribute element with static type.
Default Metric Default: 1
Sets the default metric. With the exception of connected route types, the default metric
is advertised when a metric has not been configured for a redistributed route. For
connected route types, the default metric is 1 despite the value of this parameter.
Distance Default Sets the default RIP distance.
Version Set the RIP version to accept for reads and send. The version can be either 1 or 2.
Disabling RIPv1 by specifying version 2 is STRONGLY encouraged.
5. Configure prefix lists. For more information, refer to Section 5.20.3.3, “Adding a Prefix List”.
6. Configure a network. For more information, refer to Section 5.20.4.1, “Configuring a Network”.
7. Configure the prefix list distribution. For more information, refer to Section 5.20.8.2, “Adding a Prefix List
Distribution Path”.
8. Configure key chains. For more information, refer to Section 5.20.9.3, “Adding a Key Chain”.
9. Configure redistribution metrics. For more information, refer to Section 5.20.10.2, “Adding a Redistribution
Metric”.
10. Configure interfaces. For more information, refer to Section 5.20.11.2, “Configuring a Routing Interface”.
11. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
12. Click Exit Transaction or continue making changes.
Section 5.20.2
Viewing the Status of Dynamic RIP Routes
To view the status of the dynamic RIP routes configured on the device, navigate to routing » status » rip »
route. If RIP routes have been configured, the Route table appears.
