RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Deleting a Shared Network 323
7. Click Exit Transaction or continue making changes.
Section 5.15.6.6
Deleting a Shared Network
To delete a shared network, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to services » dhcpserver » shared-network. The Shared network Configuration table appears.
Figure 343: Shared Network Configuration Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen shared network.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.15.7
Managing Subnets
Subnets control settings for each subnet that DHCP serves. A subnet can include a range of IP addresses to
give clients. Subnets contain groups, pools and hosts. Only one subnet can contain dynamic IP address ranges
without any access restrictions on any given physical port, since DHCP doesn't know which subnet a client
should belong to when the request is received.
The following sections describe how to configure and manage subnets on a DHCP server:
• Section 5.15.7.1, “Viewing a List of Subnets”
• Section 5.15.7.2, “Adding a Subnet”
• Section 5.15.7.3, “Configuring Subnet Options”
• Section 5.15.7.4, “Configuring a Subnet Client”
• Section 5.15.7.5, “Deleting a Subnet”
