Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
304 Adding a GSM Profile
If no GSM profiles have been configured, add profiles as needed. For more information, refer to Section 5.13.2.2,
“Adding a GSM Profile”.
Section 5.13.2.2
Adding a GSM Profile
To add a GSM profile for the celullar modem interface, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to global » cellular » profiles » gsm and click <Add gsm>. The Key Settings form appears.
Figure 320: Key Settings Form
1. Name Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
name Create a GSM profile name.
4. Click Add to create the new profile. The Cellular Network Configuration and GSM PPP Configuration
forms appear.
Figure 321: Cellular Network Configuration Form
1. Access Point Name Box 2. Dial String Box
