RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Adding a Network 467
If no networks have been configured, add networks as needed. For more information, refer to Section 5.19.8.2,
“Adding a Network”.
Section 5.19.8.2
Adding a Network
To add a network for the BGP protocol, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » bgp » network and click <Add option82>. The Key Settings form
appears.
Figure 526: Key Settings Form
1. Subnet Address/Prefix Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
Subnet Address/Prefix IP address/prefix.
4. Click Add to create the network.
5. If necessary, configure an event tracker to track network commands. For more information, refer to
Section 5.19.8.4, “Tracking Commands”.
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
Section 5.19.8.3
Deleting a Network
To delete a network configured for the BGP protocol, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » bgp » network. The BGP Network table appears.
