RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Viewing the Status of VRRP 583
Section 5.26.2
Viewing the Status of VRRP
To view the status of VRRP, navigate to services » vrrp » status. The VRRP Status form appears.
Figure 676: VRRP Status Form
This table provides the following information:
Parameter Description
Instance Name The VRRP instance name.
State The VRRP instance state.
Priority The VRRP instance priority.
Time of Change to Current State The time of change to the current state.
Interface State The VRRP interface state.
Section 5.26.3
Enabling/Disabling VRRP
To enable or disable VRRP, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to services » vrrp. The Virtual Router Redundancy Protocol (VRRP) form appears.
Figure 677: Virtual Router Redundancy Protocol (VRRP) Form
1. Enable VRRP Service Check Box 2. Router ID Box
3. Configure the following parameter(s) as required:
