Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
760 Deleting a Traffic Control Interface
Parameter Description
Type Synopsis: internal, external, none
Default: none
(optional) 'external' (facing toward the Internet) or 'internal'
(facing toward a local network). 'external'
causes the traffic generated by each unique
source IP address to be treated as a single
flow. 'internal' causes the traffic generated by
each unique destination IP address to be treated
as a single flow. Internal interfaces seldom
benefit from simple traffic shaping.
Ingress Speed (numerical value only) (optional) The incoming bandwidth of this interface. If incoming
traffic exceeds the given rate, received packets
are dropped randomly. When unspecified, maximum
speed is assumed. Specify only the number here.
The unit (kilobits, megabits) is specified in the in-unit.
Unit for Ingress Speed Synopsis: none, kilobits, megabits
Default: none
The unit for inbandwidth, per second.
Egress Speed (numerical value only) The outgoing bandwidth for this interface. Specify only the number
here. The unit (kilobits, megabits) is specified in the out-unit.
Unit for Egress Speed Synopsis: kilobits, megabits
Default: megabits
The unit for outgoing bandwidth, per second.
Description A description for this configuration item.
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
Section 5.37.2.3
Deleting a Traffic Control Interface
To delete a traffic control interface, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to qos » traffic-control » basic-configuration » tcinterfaces. The Basic Traffic Control
Interfaces table appears.
