Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
316 Managing Shared Networks
Figure 334: Listen Interfaces Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen DHCP listen interface.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.15.6
Managing Shared Networks
Shared networks are used when multiple subnets should be served by a single physical port. This applies both
when using a DHCP relay agent connected to the port with additional subnets behind the relay agent, or when
multiple virtual networks exist on one physical interface. Each subnet then gets its own subnet definition inside
the shared network rather than at the top level. Shared networks contain subnets, groups and hosts.
The following sections describe how to configure and manage shared networks on a DHCP server:
• Section 5.15.6.1, “Viewing a List of Shared Networks”
• Section 5.15.6.2, “Adding a Shared Network”
• Section 5.15.6.3, “Configuring Shared Network Options”
• Section 5.15.6.4, “Configuring a Shared Network Client”
• Section 5.15.6.5, “Customizing Shared Network Clients”
• Section 5.15.6.6, “Deleting a Shared Network”
Section 5.15.6.1
Viewing a List of Shared Networks
To view a list of shared networks, navigate to services » dhcpserver » shared-network. If shared networks
have been configured, the Shared network Configuration table appears.
