RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Deleting an Out-Interface 553
Figure 645: Key Settings Form
1. Ifname List 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
ifname
5. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
6. Click Exit Transaction or continue making changes.
Section 5.23.3.3
Deleting an Out-Interface
To delete an out-interface, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » multicast » static » mcast-groups » {group} » out-interface. The Outgoing
Interfaces table appears.
Figure 646: Outgoing Interfaces Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen out-interface.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
