Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
736 Managing Forbidden Ports
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to switch » vlans » static-vlan. The Static VLANs table appears.
Figure 845: Static VLANs Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen static VLAN.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.35.5
Managing Forbidden Ports
Static VLANs can be configured to exclude ports from membership in the VLAN using the forbidden ports list.
The following sections describe how to configure and manage a list of forbidden ports:
• Section 5.35.5.1, “Viewing a List of Forbidden Ports”
• Section 5.35.5.2, “Adding a Forbidden Port”
• Section 5.35.5.3, “Deleting a Forbidden Port”
Section 5.35.5.1
Viewing a List of Forbidden Ports
To view a list of forbidden ports, navigate to switch » vlans » static-vlan » {name} » forbidden-ports, where
{name} is the name of the static VLAN. If ports have been forbidden, the Forbidden Ports table appears.
Figure 846: Forbidden Ports Table
