Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
776 Configuring QoS Marking
Parameter Description
Source Ports (Optional) A comma- separated list of port names, port numbers or port ranges.
test (Optional) Defines a test on the existing packet or connection mark.
The default is a packet mark. For testing a connection mark, add ':C' at the end of the
test value. Ex.:
Test if the packet mark is not zero:
!0
Test if the connection mark is not zero:
!0:C
length (Optional) Matches the length of a packet against a specific value or range of values...
Greater than and lesser than, as well as ranges are supported in the form of min:max.
Ex.: Equal to 64 64 Greater or equal to 65 65: Lesser or equal to 65 :65 In-between 64
and 768 64:768
tos Synopsis: minimize-delay, maximize-throughput, maximize-reliability, minimize-cost,
normal-service
(Optional) Type of Service .
A pre-defined ToS value or a numerical value. The
numerical value is hexadecimal. Ex.: 0x38
description A description for this configuration item.
NOTE
Only one QoS mark is allowed for each traffic control rule.
6. Configure the rules for a QoS mark. For more information, refer to Section 5.37.6.3, “Configuring QoS
Marking”.
7. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
8. Click Exit Transaction or continue making changes.
Section 5.37.6.3
Configuring QoS Marking
Quality of Service (QoS) marking applies a mark to important data packets that should receive preferential
treatment as they travel through the network. Only one QoS mark is allowed for each traffic control rule. Options
include:
• Set: Determines whether the packet or the connection is assigned the QoS mark.
• Modify: Changes the QoS mark value using an AND or OR argument.
• Save/Restore: Replaces the connection's QoS mark value with an assigned value.
• Continue: If the packet matches, no more traffic control rules are checked and the packet is automatically
forwarded to the specified chain.
• DSCP Marking: Determines whether the packet is assign the DSCP mark.
To configure the QoS mark for a traffic control rule, do the following:
