Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
390 Configuring the Source Zone
Parameter Description
description (Optional) The description string for this policy.
7. Configure the source zone for the policy. For more information, refer to Section 5.17.11.3, “Configuring the
Source Zone”.
8. Configure the destination zone for the policy. For more information, refer to Section 5.17.11.4, “Configuring
the Destination Zone”.
9. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
10. Click Exit Transaction or continue making changes.
Section 5.17.11.3
Configuring the Source Zone
To configure the source zone for a firewall policy, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to security » firewall » fwconfig » {firewall} » fwpolicy{policy} » source-zone, where {firewall}
is the name of the firewall and {policy} is the name of the policy. The Source Zone form appears.
Figure 427: Source Zone Form
1. Pre-Defined Zone List 2. All Check Box
3. Configure the following parameter(s) as required:
Parameter Description
predefined-zone
all
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
