Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
584 Managing VRRP Trackers
Parameter Description
Enable VRRP Service Enables or disables the VRRP service.
Router ID The router ID for VRRP logs.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.26.4
Managing VRRP Trackers
VRRP trackers monitor the state/condition of a route. When the route is unavailable, VRRP will lower its priority
or transition it to a fault state.
NOTE
The decision to increase or decrease the priority of a route must be done in coordination with any
backup VRRP Routers since the priority decides whether a router becomes a Master or a Backup. For
example, if Router X's priority is 150 and Router Y's priority is 145, Router X's priority must be lowered
by 6 to make it a Backup router.
The following sections describe how to configure and manage VRRP trackers:
• Section 5.26.4.1, “Viewing a List of VRRP Trackers”
• Section 5.26.4.2, “Adding a VRRP Tracker”
• Section 5.26.4.3, “Deleting a VRRP Tracker”
Section 5.26.4.1
Viewing a List of VRRP Trackers
To view a list of VRRP trackers, navigate to services » vrrp » trackers. If trackers have been configured, the
Tracker table appears.
Figure 678: Tracker Table
If no VRRP trackers have been configured, add trackers as needed. For more information, refer to
Section 5.26.4.2, “Adding a VRRP Tracker”.
