Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
446 Configuring a Set
Parameter Description
Prefix List The prefix list name.
5. On the Match Advertising Source Address form, configure the following parameters as required:
Parameter Description
Prefix List The prefix list name.
6. On the Match form, configure the following parameters as required:
Parameter Description
AS Path Filter Match the BGP AS path filter.
Metric Match the route metric.
Peer Address This parameter is not supported and any value is ignored by the system.s
Origin Synopsis: egp, igp, incomplete
Match the BGP origin code.
7. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
8. Click Exit Transaction or continue making changes.
Section 5.19.3.8
Configuring a Set
To configure matched rules for a route map filter entry, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » bgp » filter » route-map » {tag} » entry » {number} » set, where {tag} is
the tag for the route map filter and {number} is the sequence number for the entry. The Aggregator, Metric
and Set forms appear.
Figure 497: Aggregator Form
1. AS Number Box 2. IP Address Box
