RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Viewing the Memory Statistics 249
Figure 257: IPv6 Kernel Active Routing Table
This table provides the following information:
Parameter Description
Subnet The network/prefix.
Gateway Address The gateway address.
Interface Name The interface name.
Route Type The route type.
Route Weight The route weight.
Metric The metric value.
If no IPv6 routes have been configured, add routes as needed. For more information, refer to Section 5.22.3,
“Adding an IPv6 Static Route”.
Section 5.9
Viewing the Memory Statistics
To view statistics related to the Core, RIP, OSPF and BGP daemons, navigate to routing » status » memory.
The Core Daemon Memory Statistics, RIP Daemon Memory Statistics, OSPF Daemon Memory Statistics
and BGP Daemon Memory Statistics forms appear.
