RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Adding a Neighbor 463
Figure 520: Neighbor Table
If no neighbors have been configured, add neighbors as needed. For more information, refer to Section 5.19.7.2,
“Adding a Neighbor”.
Section 5.19.7.2
Adding a Neighbor
To add a neighbor for a BGP network, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » bgp » neighbor and click <Add neighbor>. The Key Settings form
appears.
Figure 521: Key Settings Form
1. Neighbor IP Address Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
Neighbor IP address The neighbor IP address.
4. Click Add to add the address. The Route Map and Neighbor forms appear.
