Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
392 Managing Network Address Translation Settings
Figure 429: Main Policy Settings Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen policy.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.17.12
Managing Network Address Translation Settings
Network address translation entries can be used to set up a one-to-one correspondence between an external
address on the firewall and the RFC1918 address of a host behind the firewall. This is often set up to allow
connections to an internal server from outside the network.
NOTE
Destination Network Address Translation (DNAT) can be setup by configuring the destination zone in a
rule. For more information on rules, refer to Section 5.17.14, “Managing Rules”.
The following sections describe how to configure and manage network address translation settings for a firewall:
• Section 5.17.12.1, “Viewing a List of NAT Settings”
• Section 5.17.12.2, “Adding a NAT Setting”
• Section 5.17.12.3, “Deleting a NAT Setting”
Section 5.17.12.1
Viewing a List of NAT Settings
To view a list of NAT settings, navigate to security » firewall » fwconfig » {firewall} » fwnat, where {firewall} is
the name of the firewall. If NAT settings have been configured, the Net Address Translation Main Settings table
appears.
