RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Managing Network IP Address 487
Figure 552: Track Form
1. Track Event List 2. Apply When List
5. Configure the following parameter(s) as required:
Parameter Description
Track Event Selects an event to track. The distribute-prefix-list is applied only when the tracked event
is in the UP state.
Apply When Synopsis: up, down
Default: up
Determines when to apply the distribute-prefix-list when the tracked event is in the UP or
DOWN state.
6. Click Add to create the tracker.
7. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
8. Click Exit Transaction or continue making changes.
Section 5.20.5
Managing Network IP Address
The following sections describe how to configure and manage network IP addresses for dynamic RIP routes:
• Section 5.20.5.1, “Viewing a List of Network IP Addresses”
• Section 5.20.5.2, “Adding a Network IP Address”
• Section 5.20.5.3, “Deleting a Network IP Address”
Section 5.20.5.1
Viewing a List of Network IP Addresses
To view a list of IP addresses configured for a RIP network, navigate to routing » dynamic » rip » network » ip.
If addresses have been configured, the Subnet table appears.
