RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Managing Neighbors 491
Figure 558: Interface Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen interface.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.20.7
Managing Neighbors
Neighbors are other routers with which to exchange routes.
The following sections describe how to configure and manage neighbor IP addresses for dynamic RIP routes:
• Section 5.20.7.1, “Viewing a List of Neighbors”
• Section 5.20.7.2, “Adding a Neighbor”
• Section 5.20.7.3, “Deleting a Neighbor”
Section 5.20.7.1
Viewing a List of Neighbors
To view a list of neighbors configured for a RIP network, navigate to routing » dynamic » rip » network »
neighbor. If neighbors have been configured, the Neighbor table appears.
Figure 559: Neighbor Table
If no neighbors have been configured, add neighbors as needed. For more information, refer to Section 5.20.7.2,
“Adding a Neighbor”.
