RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Viewing the IPsec Tunnel Status 617
6. Navigate to tunnel » ipsec » connection » {connection} » {end}, where {connection} is the name of the
connection and {end} is the either the left (local router) or right (remote router) connection end. The System
Public Key and System Identifier forms appear.
Figure 718: System Public Key Form
1. Type List 2. Certificate List (Hidden) 3. RSA Signature List (Hidden)
Figure 719: System Identifier Form
1. Type List 2. Hostname or IP Address
7. On the System Public Key form, set Type to certificate. The Certificate parameter appears.
8. Under the Certificate list, select the appropriate certificate.
9. On the System Identifier form, set Type to from-certificate.
10. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
11. Click Exit Transaction or continue making changes.
Section 5.28.4
Viewing the IPsec Tunnel Status
To view the status of the IPsec tunnel, navigate to tunnel » ipsec. The IPSec Status form appears.
