Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
266 Adding an SNMP Target Address
Figure 272: SNMPv3 Target Configuration Table
If no SNMP target addresses have been configured, add target addresses as needed. For more information, refer
to Section 5.11.6.2, “Adding an SNMP Target Address”.
Section 5.11.6.2
Adding an SNMP Target Address
To add an SNMP target adress, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to admin » snmp » snmp-target-address and click <Add snmp-target-address>. The Key
Settings form appears.
Figure 273: Key Settings Form
1. Target Name Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
Target Name A descriptive name for the target (ie. 'Corportate NMS').
4. Click Add to create the protocol. The SNMPv3 Target Configuration screen appears.
