RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Validating a Firewall Configuration 405
Figure 443: Main Rule Settings Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen rule.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.17.15
Validating a Firewall Configuration
To validate a firewall configuration, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to security » firewall. The Firewall Configuration form appears.
Figure 444: Firewall Configuration Form
1. Enable Active Configuration Check Box 2. Specify Work Configuration List 3. Specify Active Configuration List
3. Under Specify work configuration, select the firewall configuration from the list.
4. Click Commit to save the changes. The system validates the firewall configuration and displays the results.
5. Click Exit Transaction or continue making changes.
