RUGGEDCOM ROX II
User Guide
Chapter 3
Device Management
Viewing the CDMA Network Status for Cellular Modems 145
Section 3.23.5
Viewing the CDMA Network Status for Cellular Modems
To view the status of the CDMA network for a cellular modem, navigate to interfaces » cellmodem » {slot/port/
profile} » cdma, where {slot/port/profile} is the slot name, port number and profile configured for the cellular
modem. The 3G CDMA/EVDO Cellular Modem Information form appears.
Figure 149: 3G CDMA/EVDO Cellular Modem Information Form
1. Network Supported 2. ESN 3. ECIO 4. RSSI Indicator 5. Network Operator 6. Network In Use 7. Network Status 8. Phone
Number
This form provides the following information:
Parameter Description
network-supported Wireless technologies supported by the modem
esn The Electronic Serial Number of the modem. ESN is only avaible for the CDMA modem.
ecio The total energy per chip per power density value in dBm
rssi-indicator The Received Signal Strength Indicator in dBm
network-operator The wireless network operator currently in use
network-in-use The network technology currently in use by the modem
network-status The registration status of the modem with the wireless network
phone-number The subscriber phone number of the CDMA modem
