Chapter 3
Device Management
RUGGEDCOM ROX II
User Guide
172 Deleting a Data Link
Figure 181: On Demand Form
1. On Demand Check Box 2. MTU Box
6. Configure the following parameter(s) as required:
Parameter Description
On Demand This interface is up or down on demand of link fail over.
MTU Default: 1500
Maximum transmission unit (largest packet size allowed for this interface).
7. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
8. Click Exit Transaction or continue making changes.
Section 3.24.14.3
Deleting a Data Link
To delete a data link for a frame relay connection, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to interface » wan » {interface} » {protocol} » channel » {number} » connection »
framerelay » dlci, where {interface} is the WAN interface, {parameter} is either T1 or E1, and {number} is the
channel number. The On Demand table appears.
