Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
404 Deleting Rules
Figure 442: Destination Zone Form
1. Pre-Defined Zone List 2. Other Box 3. All Check Box
3. Configure the following parameter(s) as required:
Parameter Description
predefined-zone A pre-defined zone
other An undefined zone (string).
all All zones
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.17.14.5
Deleting Rules
To delete a rule, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to security » firewall » fwconfig » {firewall} » fwrule, where {firewall} is the name of the firewall.
The Main Rule Settings table appears.
