Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
450 Adding an Excluded Autonomous System Path filter
Figure 502: Key Settings Form
1. AS Number Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
AS Number AS number.
5. Click Add to add the filter.
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
Section 5.19.4.4
Adding an Excluded Autonomous System Path filter
To add an excluded autonomous system path filter to a BGP route map entry, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » bgp » filter » route-map » {name} » entry » {number} » set » as-path »
exclude, where {name} is the name of the route map and {number} is the entry number.
3. Click <Add prepend>. The Key Settings form appears.
