RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Viewing a List of Interfaces 379
Section 5.17.9.1
Viewing a List of Interfaces
To view a list of interfaces, navigate to security » firewall » fwconfig » {firewall} » fwinterface, where {firewall}
is the name of the firewall. If interfaces have been configured, the Main Interface Settings table appears.
Figure 412: Main Interface Settings Table
If no interfaces have been configured, add interfaces as needed. For more information, refer to Section 5.17.9.2,
“Adding an Interface”.
Section 5.17.9.2
Adding an Interface
To configure an interface for a firewall, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to security » firewall » fwconfig » {firewall} » fwinterface, where {firewall} is the name of the
firewall.
3. Click <Add fwinterface> in the menu. The Key Settings form appears.
Figure 413: Key Settings Form
1. Interface Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
interface Currently active or not - add '+' for the same interfaces: ppp+.
5. Click Add. The Main Interface Settings and Interface Options forms appear.
