512 Viewing the Status of Dynamic OSPF Routes
Section 5.21.3
Viewing the Status of Dynamic OSPF Routes
To view the status of the dynamic OSPF routes configured on the device, navigate to routing » status » ospf »
route » network. If OSPF routes have been configured, the Network table appears.
Figure 585: Network Table
The Network table provides the following information:
Parameter Description
id Network Prefix.
discard This entry is discarded entry.
inter-area Is path type inter area.
cost Cost.
area Area.
If no dynamic OSPF routes have been configured, configure OSPF and add routes as needed. For more
information about configuring OSPF, refer to Section 5.21.2, “Configuring OSPF”.
Section 5.21.4
Managing Prefix Lists and Entries
Neighbors can be associated with prefix lists, which allow the OSPF daemon to filter incoming or outgoing routes
based on the allow and deny entries in the prefix list.
The following sections describe how to configure and manage prefix lists and entries for dynamic OSPF routes:
• Section 5.21.4.1, “Viewing a List of Prefix Lists”
• Section 5.21.4.2, “Viewing a List of Prefix Entries”
• Section 5.21.4.3, “Adding a Prefix List”
• Section 5.21.4.4, “Adding a Prefix Entry”
• Section 5.21.4.5, “Deleting a Prefix List”
• Section 5.21.4.6, “Deleting a Prefix Entry”
