RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Configuring OSPF 511
Figure 584: Default Information Originate Form
1. Always Advertise Default Route Enable Check Box 2. Metric Box 3. Metric Type Box 4. Route Map List
6. In the Default Information Originate form, configure the following parameters:
Parameter Description
Always Advertise Default Route Default: false
Always advertise default route even when there is no default route present in routing
table.
Metric The metric value for default route.
Metric Type Default: 2
The mtric type for default route.
Route Map The route map name.
7. Configure prefix list filters. For more information, refer to Section 5.21.4.3, “Adding a Prefix List”.
8. Configure areas. For more information, refer to Section 5.21.5.2, “Adding an Area”.
9. Configure route map filters. For more information, refer to Section 5.21.6.3, “Adding a Route Map Filter”.
10. Configure redistribution metrics. For more information, refer to Section 5.21.8.2, “Adding a Redistribution
Metric”.
11. Configure interfaces. For more information, refer to Section 5.21.9.2, “Configuring a Routing Interface”.
12. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
13. Click Exit Transaction or continue making changes.
