Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
510 Configuring OSPF
Parameter Description
Inter Area Routes Distance The administrative distance for inter-area routes.
intra Area Routes Distance The administrative distance for intra-area routes.
4. In the OSPF Configuration form, configure the following parameters:
Parameter Description
Enable OSPF Enables the OSPF dynamic routing protocol.
ABR Type Synopsis: cisco, ibm, shortcut, standard
Default: cisco
The OSPF ABR type.
Auto Cost Reference Bandwidth Default: 100
Calculates the OSPF interface cost according to bandwidth [1-4294967 Mbps]
Compatible with RFC1583 Enables the compatibility with the obsolete RFC1583 OSPF (the current is RFC2178)
Default Information Originate Advertises the default route.
Default Metric The default metric of redistribute routes.
Distance The administrative distance.
Enable Opaque-LSA capability Enables the Opaque-LSA capability (rfc2370).
Passive Default Default: true
Default passive value for new interface.
Refresh Timer Default: 10
The refresh timer.
Router ID The Router ID for OSPF.
5. If you checked the Default Information Originate Check Box in the OSPF Configuration form, the Default
Information Originate form appears.
