Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
546 Viewing a List of Interfaces for IPv4 Static Routes
Figure 634: Static Route Using Interface Form
1. Interface Name Box 2. Distance Box
4. Configure the following parameter(s) as required:
Parameter Description
Interface Name The interface for the static route.
Distance (optional) The distance for the static route.
5. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
6. Click Exit Transaction or continue making changes.
Section 5.22.7.2
Viewing a List of Interfaces for IPv4 Static Routes
To view a list of interfaces assigned to an IPv4 static route, navigate to routing » static » ipv4 » {subnet} » dev,
where subnet is the subnet (network/prefix) of the static route. If interfaces have been configured, the Static
Route Using Interface table appears.
Figure 635: Static Route Using Interface Table
If no interfaces have been configured, add interfaces as needed. For more information, refer to Section 5.22.7.3,
“Adding an Interface for an IPv4 Static Route”.
Section 5.22.7.3
Adding an Interface for an IPv4 Static Route
To add an interface for an IPv4 static route, do the following:
