RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Configuring Neighbor Discovery 817
NOTE
MPLS must be enabled and MPLS label bindings must be removed before enabling LDP. Refer to
Section 5.39.3, “Enabling/Disabling MPLS Routing” and Section 5.39.5.4, “Deleting a Static Label”
for further information.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.39.7.7
Configuring Neighbor Discovery
To configure the LDP neighbor discovery, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to mpls » ldp » discovery. The LDP Discovery Hello Configuration form appears.
Figure 945: LDP Discovery Hello Configuration Form
1. LDP Hello Interval Box 2. LDP Hello Holdtime Box
3. Configure the following parameter(s) as required:
Parameter Description
LDP Hello Interval Default: 5
The time (in seconds) between the sending of consecutive Hello messages.
LDP Hello Holdtime Default: 15
The time (in seconds) that a discovered LDP neighbor is remembered without receipt of
an LDP Hello message from the neighbor.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
