Chapter 3
Device Management
RUGGEDCOM ROX II
User Guide
166 Configuring a Multi Link PPP Connection
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
Section 3.24.11
Configuring a Multi Link PPP Connection
To configure a Multi Link Point-to-Point Protocol (MLPPP) connection for a T1 or E1 line, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to interface » wan » {interface} » {protocol} » channel » {number} , where {interface} is the
WAN interface, {protocol} is either T1 or E1, and {number} is the channel number.
3. Click the + symbol in the menu to next to mlppp. The Multilink PPP form appears.
Figure 175: Multilink PPP Form
1. Bundle Box 2. On Demand Check Box 3. MTU Box
4. Configure the following parameter(s) as required:
Parameter Description
bundle Default: 1
The bundle number
On Demand This interface is up or down on demand of link fail over.
MTU Default: 1500
Maximum transmission unit (largest packet size allowed for this interface).
5. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
6. Click Exit Transaction or continue making changes.
