Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
294 Adding a Server Key
If no server keys have been configured, add keys as needed. For more information, refer to Section 5.12.13.2,
“Adding a Server Key”.
Section 5.12.13.2
Adding a Server Key
To add a server key, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to services » time » ntp » key and click <Add key>. The Key Settings form appears.
Figure 307: Key Settings Form
1. Key ID Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
Key ID The name of the key.
4. Click Add to create the new key. The Server Keys form appears.
Figure 308: Server Keys Form
1. Key Box 2. Trusted Check Box
