Chapter 5
Setup and Configuration
RUGGEDCOM ROX II
User Guide
274 Deleting an SNMP Security Model
Figure 282: SNMP Security Model to Group Mapping Form
1. Group Box
5. Configure the following parameter(s) as required:
Parameter Description
Group Default: all-rights
The name of the SNMP group.
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
Section 5.11.8.3
Deleting an SNMP Security Model
To delete an SNMP security model, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to admin » snmp » snmp-security-to-group. The SNMP Security Model to Group Mapping
table appears.
Figure 283: SNMP Security Model to Group Mapping Table
1. Add Button 2. Edit Button 3. Delete Button
