RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Deleting a Routing Map Filter 443
7. Configure the match rules for the route map filter. For more information, refer to Section 5.19.3.7,
“Configuring Match Rules”.
8. Configure a set for the route map filter. For more information, refer to Section 5.19.3.8, “Configuring a Set”.
9. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
10. Click Exit Transaction or continue making changes.
Section 5.19.3.5
Deleting a Routing Map Filter
To delete a route map filter for dynamic BGP routes, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » bgp » filter » route-map. The Route Map table appears.
Figure 491: Route Map Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen filter.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 5.19.3.6
Deleting a Routing Map Filter Entry
To delete an entry for a route map filter, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » bgp » filter » route-map » {tag} » entry, where {tag} is the tag for the
route map filter. The Route Map Entry table appears.
