Chapter 3
Device Management
RUGGEDCOM ROX II
User Guide
56 Managing the Software Configuration
Figure 48: Remote Server Selector Table
1. Add Button 2. Edit Button 3. Delete Button
3. Click Delete next to the chosen remote server selector.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 3.10
Managing the Software Configuration
Configuration parameters for ROX II can be saved on the device and loaded in the future.
The following sections describe how to save and load the ROX II software configuration:
• Section 3.10.1, “Saving the Configuration”
• Section 3.10.2, “Loading a Configuration”
Section 3.10.1
Saving the Configuration
To save the configuration settings for ROX II as a separate file, do the following:
1. Navigate to admin and click full-configuration-save in the menu. The Full Configuration Save and
Trigger Action forms appear.
