RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Viewing a List of Gateways for IPv4 Static Routes 543
Parameter Description
Distance (optional) The distance for the static route.
5. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
6. Click Exit Transaction or continue making changes.
Section 5.22.6.2
Viewing a List of Gateways for IPv4 Static Routes
To view a list of gateway addresses assigned to an IPv4 static route, navigate to routing » static » ipv4 »
{subnet} » via, where subnet is the subnet (network/prefix) of the static route. If addresses have been
configured, the Static Route Using Gateway table appears.
Figure 630: Static Route Using Gateway Table
If no gateway addresses have been configured, add addresses as needed. For more information, refer to
Section 5.22.6.3, “Adding a Gateway for an IPv4 Static Route”.
Section 5.22.6.3
Adding a Gateway for an IPv4 Static Route
To add a gateway address for an IPv4 static route, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » static » ipv4 » {subnet} » via, where subnet is the subnet (network/prefix) of the
static route.
3. Click <Add via>. The Key Settings form appears.
