RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Adding a Virtual IP Address 599
If no virtual IP addresses have been configured, add addresses as needed. For more information, refer to
Section 5.26.9.2, “Adding a Virtual IP Address”.
Section 5.26.9.2
Adding a Virtual IP Address
To add a virtual IP address, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to services » vrrp » instance » {name} » vrip, where {name} is the name of the VRRP instance.
3. Click <Add vrip>. The Key Settings form appears.
Figure 698: Key Settings Form
1. Virtual IP Address/Netmask Box 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
Virtual IP Address/Netmask The virtual IP address/netmask.
5. Click Add to add the virtual IP address.
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
Section 5.26.9.3
Deleting a Virtual IP Address
To delete a virtual IP address, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to services » vrrp » instance » {name} » vrip, where {name} is the name of the VRRP instance.
The VRIP IP Address table appears.
