RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Viewing a List of Connections 621
• Section 5.28.6.3, “Configuring Dead Peer Detection”
• Section 5.28.6.4, “Deleting a Connection”
Section 5.28.6.1
Viewing a List of Connections
To view a list of connections configured for a VPN, navigate to tunnel » ipsec » connection. If connections have
been configured, the Connection table appears.
Figure 725: Connection Table
If no connections have been configured, add connections as needed. For more information, refer to
Section 5.28.6.2, “Adding a Connection”.
Section 5.28.6.2
Adding a Connection
To add a new connection for a VPN, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to tunnel » ipsec » connection and click <Add connection>. The Key Settings form appears.
Figure 726: Key Settings Form
1. Connection Name Box 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
Connection Name Synopsis: default,
