RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Deleting a Redistribution Metric 503
Figure 576: Key Settings Form
1. Redistribute Type List 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
Redistribute Type Synopsis: kernel, static, connected, ospf, bgp
Redistribute route type.
4. Click Add to add the metric. The Redistribute Route from Other Protocols form appears.
Figure 577: Redistribute Route from Other Protocols Form
1. Metric Box
5. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
6. Click Exit Transaction or continue making changes.
Section 5.20.10.3
Deleting a Redistribution Metric
To delete a redistribution metric for dynamic RIP routes, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » rip » redistribute. The Redistribute Route from Other Protocols table
appears.
